Top View of Assembly
A
SECTION A-A
End View of Assembly
SECTION A-A
Without Optional Bottom Panel
254.00
[10.00]
223.84
[8.81]
B
A
401.64
[15.81]
B
2.38
[.09]
2.24
[.09]
76.20
[3.00]
70.49
[2.78]
(Inner Box Height)
13.86
[.55]
11.83
[.47]
88.03
[3.47]
431.80
[17.00]
? 5.79
Top View of Frame
SECTION B-B
Side View of Assembly
[.23]
17.96
[.71]
19.05
[.75]
15.00
[.59]
1.14
[.05]
28.58
[1.13]
158.75
[6.25]
215.90
[8.50]
(Inside Box Width)
393.70
[15.50]
(Inside Box Length)
Enclosures can be Factory Modified ( Milling, Drilling, Printing etc.)
Contact Factory mjm@hammondmfg.com for quotes
Solid models of this enclosure available in STEP or IGES.
NOTE
336.55
[13.25]
Chassis ? Includes ? Solid ? Walnut ? Frame, ? one ? (1) ? Aluminum ? Panel, ?
Rubber ? Feet ? and ? Required ? Hardware
Aluminum ? Panels ? are ? Made ? of ? 0.080" ? Aluminum.
HW1710ALPL
HWCHAS1710BK
? 6.05
[.24]
222.25 203.20
[8.75] [8.00]
Aluminum Panel
(Top or Bottom)
381.00
[15.00]
2.03
[.080]
Screws should not be torqued past 4.43 lbf.in (50 cN.m)
PART NUMBERS
17''x10'' Enclosure (Natural Finish)
Chassis with Natural Finish Panel
HWCHAS1710AL
Natural Finish Panel
17''x10'' Enclosure (Satin Black)
Chassis with Satin Black Panel
Satin Black Panel
HW1710BKPL
400.05
[15.75]
Dimensions:
mm
[inches]
HWCHAS1710
